| Specification | Description |
|---|---|
| Max Turning dia | 12 3/16" |
| Max. Turning Length | 19 5/8" |
| Max Swing Y-axis Stroke | 3.8" |
| Dist Between Spindle Faces | 27.5" |
| Chuck Dia | 8" Main spindle |
| Chuck Dia | 6" Sub-spindle |
| Spindle Speed Range Main | 40~4000 Rpm |
| Spindle Speed Sub-spindle | 40~4000 Rpm |
| Spindle Nose (both) | A2-6 |
| Bar Work Capacity Main Spindle | 2 5/8" |
| Bar work Capacity Sub-spindle | 1.77" |
| Tooling stations | 12 Station Turret |
| Main Spindle Motor | 35 Hp |
| Sub-Spindle Motor | 10 Hp |
| Rotary tool Hp | 5 Hp |
| Mass of Machine | 15,200 lbs |
