| Specification | Description |
|---|---|
| Swing | 39.17" |
| Max. turning Diamter | 16.5" |
| Max. turning Length | 49.6" |
| Spindle bore | 4.13" |
| spindle speed | 30 ~ 3000 Rpm |
| Turret | 12 Station |
| Rotary (Live) Tool Stations on Turrets | 7.5 HP |
| Main spindle drive | 40/30 Hp |
| Rotary tool spindle speed | 6000 Rpm |
| Travels: X, Z, Y, C | 11.03"/53.9"/4.7"/ .001 Degree |
| Machine Weight | 18,000 Lbs |
Used Solutions, Inc.
761 Ridgeview Dr.
McHenry, Illinois 60050
815-759-5000
815-669-2097
info@usedsolutions.com
